Porcelain Arrester

Inquire Now Next Product

Product Description

Porcelain Arrester

Products Description

Porcelain Arrester

Power station porcelain housing lightning arrester 5kA/10kA/20kA

Nominal discharge current at 5kA
Model type	Rated voltage(kV)	Continuous operating voltage(kV)	DC U1mA reference voltage(kV)	Residual voltage(kV)			Discharge current		0.75 U1mA leakage current ≤(μA)	Creepage distance(mm/kV)
				Lightning impulse current 8/20μs	Steep current impulse 1/10μs	Switching impulse current 30/60μs	2ms rectangular current impulse withstand(A)	4/10 μs high current(KA)
											Y5W-17/45	17	13.6	24	45	51.8	38.3	150	65	50	31
											Y5W-51/134	51	40.8	73	134	154	114	400	65	50	41.3
Y5W-51/122	51	40.8	73	122	140	104	400	65	50	41.3
Y5W-54/134	54	43.2	76	134	151	114	400	65	50	41.3
Y5W-90/235	90	72.5	130	235	270	201	600	65	50	36.9
Y5W-96/232	96	75	134	232	267	198	600	65	50	36.9
Y5W-96/250	96	75	140	250	288	213	600	65	50	25.6/31
Y5W-100/260	100	78	145	260	299	221	600	65	50	25.6/31
Y5W-102/266	102	79.6	148	266	305	226	600	65	50	25.6/31
Y5W-108/281	108	84	157	281	323	239	600	65	50	25.6/31

Nominal discharge current at 10kA
Model type	Rated voltage(kV)	Continuous operating voltage(kV)	DC U1mA reference voltage(kV)	Residual voltage(kV)			Discharge current		0.75 U1mA leakage current ≤(μA)	Creepage distance(mm/kV)
				Lightning impulse current 8/20μs	Steep current impulse 1/10μs	Switching impulse current 30/60μs	2ms rectangular current impulse withstand(A)	4/10 μs high current(KA)
											Y10W-90/235	90	72.5	130	235	261	201	600	100	50	36.9
											Y10W-96/232	96	75	134	232	267	198	600	100	50	36.9
Y10W-96/250	96	75	140	250	280	213	600	100	50	36.9
Y10W-100/260	100	78	145	260	291	221	600	100	50	25.6/31
Y10W-102/266	102	79.6	148	266	297	226	600	100	50	25.6/31
Y10W-108/281	108	84	157	281	315	239	600	100	50	25.6/31
Y10W-192/500	192	150	280	500	560	426	600	100	50	25.6/31
Y10W-200/520	200	156	290	520	582	442	600	100	50	25.6/31
Y10W-200/496	200	156	290	496	556	422	600	100	50	25.6/31
Y10W-204/532	204	159	296	532	591	452	600	100	50	25.6/31
Y10W-216/562	216	168.5	314	562	630	478	600	100	50	25.6/31
Y10W-288/670	288	210	408	670	730	582	1000	100	50	31.2
Y10W-300/727	300	228	425	727	814	618	1000	100	50	31.2
Y10W-312/760	312	237	442	760	847	643	1000	100	50	31.2

Nominal discharge current at 20kA
Model type	Rated voltage(kV)	Continuous operating voltage(kV)	DC U1mA reference voltage(kV)	Residual voltage(kV)			Discharge current		0.75 U1mA leakage current ≤(μA)	Creepage distance(mm/kV)
				Lightning impulse current 8/20μs	Steep current impulse 1/10μs	Switching impulse current 30/60μs	2ms rectangular current impulse withstand(A)	4/10 μs high current(KA)
											Y20W-420/1046	420	318	565	1046	1170	858	1800	100	50	31.2
											Y20W-444/1106	444	324	597	1106	1238	907	1800	100	50	31.2

Packing&Delivery

1.Your inquiry will be replied within 24 hours.
2. We offer you professional service in fluent English.
3. Keep the mass production as the sample in high quality.
4. Freight forwarder: faster, safer, and convenient.
5. Quality: we have QC on each process, provide high quality products.
Any problem or needed please feel free let us know, we are glad to service for you.
We are factory, we can provide competitive price. And all the products will be shipped after quality inspection. Usually we quote within 24 hours after we get your inquiry. If you can not buy our product in your local area, we will ship a sample to you (Please contact our agent or send email to our mailbox).

Porcelain Arrester

Packing
Packaging Details:carton, wooden cases, woven bag, plastic bag then put on pallets

We usually use standard carton Wooden pallet packaging.Other packaging is based upon customer requirements

Delivery Detalis: Within two weeks

Contact Me

If you are interested in our products, please feel free to contact me！

We are ready to help you develop the market with our high-quality products at any time, and we also hope to become your Chinese supplier to provide the best support and service for your ongoing and future projects.

Company Profile

Porcelain Arrester


EP manufacture & supply the full range of Power Accessories
	Cutout fuse	Lightning Arrestor	Polymeric composite insulator
Transmission and Distribution overhead line hardware	Stay Set	Overhead Line Steelwork	Preformed fittings	Strain clamp
	Suspension clamp	Eye bolt	Pigtail hook	Connector fittings
	Fasteners	Protective fittings	Anchor Rod	Galvanized Ground Rod/Earth Rod
	Terminal Connector and Cable lug	Splicing Fittings
ABC cable Fittings	Insulation Piercing connector	Dead End Clamp	Suspension Clamp	PG Clamp
ABC cable Fittings	Anchor Bracket	Pre-Insulated Sleeve
	Hot Dip Galvanized Steel Strand Wire	Stay wire
Electrical Safety Tools	Insulating Gloves	Rubber Insulating Boots	Portable Earthing Whole Sets	Discharge Sticks
	Fiberglass Operating Sticks	Safety Climbing Harness /belt	Pole Climber	Safety Helmet
	Wire Grip Tightener

Porcelain Arrester

Please click the link in the description for more product information！

www.electricpowertek.com

Partner customers

Porcelain Arrester

Cooperative Client

Our cooperative client are all over the world and our products are very popular all over the world. Many products are exported to Russia, USA, Australia, Canada, South Africa, Kenya, Tanzania, Zambia, Brazil and Argentina. Chile, Southeast Asian countries and other international markets. With first-class technical ability and perfect pre-sale and after-sales service guarantee system, we have established a good reputation between enterprises and users.

FAQ

Q: Do you provide sample service?
A: Yes, we only provide samples and ask for one piece at a time. The freight should be borne by you.
Q: Do you support customized services？
A: Yes, we can customize the size and logo according to your needs. Please consult the customer service for the specific minimum order quantity.
Q: How is the Design & Engineering?

A: Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project. If you require more complex engineering of structures such as overhead transmission and distribution lines design,we can also provide this service also designer fee .

Q: What's the payment term?
A: We accept T/T, L/C, West Union.
Q: What's the delivery time?
A: Usually within 7-15 days according to quantities
Q: What's the standard of package?
A: Export standard package or special package as the requirement of customers.
Q: What kind of product quality your factory offer?
A: Our products with both excellent quality and competitive price. And we offer free sample for your reference.
Q: What kind of certificate you have?
A: We have ISO9001:2008
