Product Description
CAPG Cu-Al Parallel Groove Clamp is used for the Non-bearing connection and offset of aluminum stranded wire, aluminum stranded wire, it's used with insulating cover for the effect of protective and insulation.
Model | Conductor Cross-section (mm2) | Bolts |
CAPG-A1 | Cu 6-50 Al 16-70 | 1×M8×40 |
CAPG-A2 | Cu 10-95 Al 25-150 | 1×M8×45 |
CAPG-B1 | Cu 6-50 Al 16-70 | 2×M8×45 |
CAPG-B2 | Cu 10-95 Al 25-150 | 2×M8×50 |
CAPG-B3 | Cu 25-185 Al 35-200 | 2×M10×60 |
CAPG-C1 | Cu 6-50 Al 16-70 | 3×M8×45 |
CAPG-C2 | Cu 10-95 Al 25-150 | 3×M8×50 |
CAPG-C3 | Cu 25-185 Al 35-240 | 3×M10×60 |
CAPG-C4 | Cu 35-240 Al 35-300 | 3×M10×70 |
There are several instances where you are compelled to install conductors parallel to each other. One of them is when you want to install a second conductor in a closed loop. Such applications require you to buy a parallel grove clamp.
A parallel groove clamp comprises two components, the upper part, and the lower side. They are drawn together to exert the clamping force on the transmission line. This can be a power line or a telecommunication cable.
The groove clamps are made of heavy-duty aluminum which is strong and resistant to various forms of chemical and physical damage. The aluminum metal also provides takes the excessive clamping force that is required when clamping parallel conductors. It also provides resistance to UV-rays.
The parallel groove conductors feature a ‘precise fit’ design. This allows it to be clamped accurately and offer the desired support. The design also allows the clamp to support different conductor sizes. The parallel groove provides a platform onto which the conductor will rest.
Features
Has pressure pads on its edges to withstand the excessive clamping force
Comes with high strength to complete the connection during the installation
Provides a perfect electrical contact while minimizing corrosion
Pressure is uniformly distributed across the clamp
Resistant to high-temperature changes
It is a transmission line accessory that is used for connecting parallel conductors but still ensures that they don’t come in direct contact. This is mainly achieved because of the parallel grooves which provide the resting points for each conductor.
The power line accessory is polished and varnished with UV-resistant material to resist the effects of the UV rays. The grooves also shield the conductors from the effects of corrosion and damage due to physical contact.
Parallel groove clamps come in different dimensions. This is to make them compatible and usable in their respective areas of applications. A variety of dimensions also ensures that it can hold onto different conductors.
Yes. We customize the parallel grooves depending on the needs of our clients. We can tweak the shape and design of the parallel groove clamp according to your specifications.
You simply need to bring the upper and lower parts of the clamp together then close the bolts onto their respective positions. Of course the lines will be passing through the grooves.
Packing&Delivery
Partner customers
Cooperative Client
Our cooperative client are all over the world and our products are very popular all over the world. Many products are exported to Russia, USA, Australia, Canada, South Africa, Kenya, Tanzania, Zambia, Brazil and Argentina. Chile, Southeast Asian countries and other international markets. With first-class technical ability and perfect pre-sale and after-sales service guarantee system, we have established a good reputation between enterprises and users.
FAQ
Q: Do you provide sample service?
A: Yes, we only provide samples and ask for one piece at a time. The freight should be borne by you.
Q: Do you support customized services？
A: Yes, we can customize the size and logo according to your needs. Please consult the customer service for the specific minimum order quantity.
Q: How is the Design & Engineering?
A: Experienced and skilled team of designers including CAD designers and 3D designers has the capacity to deliver outstanding designs for your project. If you require more complex engineering of structures such as overhead transmission and distribution lines design,we can also provide this service also designer fee .
Q: What's the payment term?
A: We accept T/T, L/C, West Union.
Q: What's the delivery time?
A: Usually within 7-15 days according to quantities
Q: What's the standard of package?
A: Export standard package or special package as the requirement of customers.
Q: What kind of product quality your factory offer?
A: Our products with both excellent quality and competitive price. And we offer free sample for your reference.
Q: What kind of certificate you have?
A: We have ISO9001:2008
