Code:STC Cable
Size:16-25mm²
Application:
The Anchoring clamp for insulated overhead conductors self-supporting is designed to anchor insulated service lines with 2 or 4 conductors. The clamp is composed of a body, 2 wedges and removable and adjustable bail.
Features
Tool free installation with wedges sliding inside the body
Easy to open bail permits fixing to brackets and pigtails
Adjustable length of bail in three steps, max. length of clamp 208 mm
Exceeds requirements according to NF C 33 042
Clamp made of weather and UV resistant polymer
Adjustable link made of hot dip galvanized steel
Technical specification
Dimension | ||
Weight: | ||
Cable Size: | 4*(16-25) mm² | |
Mechanical | ||
Breaking Load | ||
Specification | ||
Use: | For dead-ending of cables with round shape. | |
Construction | Component | Material |
Body and Wedge | Weather and UV-radiation resistant thermoplastic | |
Bail | Hot-dip galvanized steel | |
Installation | The clamp is opened and the messenger wire is inserted between the wedge and the body. The clamp is then closed and strained. | |
Standard | NFC 33-042; EN 50-483 | |
Model | Coss-section (mm2) |
STA | 1×10/1×16 |
STB | 2×16/2×25 |
STC | 4×16/4×25 |
STD | 1×16/1×70 |
LA1 | 4×16/4×25 |
LA2 | 2×6/2×16 |
DCR-1 | 1×4/1×25 |
DCR-2 | 1×4/1×25 |
2.1 | 16-25 |
PA1500 | 25-50 |
PA2000 | 54.6-70 |
