Code:STA Cable
Size:10-16mm²
House service UV Protect Dead End Clamp is suitable for insulated low-voltage ABC cable. It is also suitable for multiple conductors.
Material：Nylon plus fiber glass
Product property：They plastic anchoring clamp is suitable for insulated low-voltage ABC cable .It is also suitable for multiple conductors
Easy installation and perfect insulated function .It is in accordance with the NFC 33-042 .
Technical specification
Dimension | ||
Weight: | 108g | |
Cable Size: | 10-16 mm² | |
Mechanical | ||
Breaking Load | 4kN | |
Specification | ||
Use: | For dead-ending of cables with round shape. | |
Construction | Component | Material |
Body and Wedge | Weather and UV-radiation resistant thermoplastic | |
Bail | Hot-dip galvanized steel | |
Installation | The clamp is opened and the messenger wire is inserted between the wedge and the body. The clamp is then closed and strained. | |
Standard | NFC 33-042; EN 50-483 | |
Model | Coss-section (mm2) |
STA | 1×10/1×16 |
STB | 2×16/2×25 |
STC | 4×16/4×25 |
STD | 1×16/1×70 |
LA1 | 4×16/4×25 |
LA2 | 2×6/2×16 |
DCR-1 | 1×4/1×25 |
DCR-2 | 1×4/1×25 |
2.1 | 16-25 |
PA1500 | 25-50 |
PA2000 | 54.6-70 |
