Code: EP117
Cable Size:4*(50-120)mm²
For the termination of 4-core LV ABC cable with hook fixing .The clamps have strong splings which keep the clamp in an open position during the installation of conductors .The clamping action functions through wedges .The body is made of weather resistant aluminium alloy and the plastic parts of special fibreglass reinforced plastic .
Technical specification
Code | EP116 | EP117 | EP118 |
Weight | |||
Cable Size | 4*(25-35)mm² | 4*(50-120)mm² | 4*(50-120)mm² |
Breaking Load | |||
Use | This anchoring assembly is used for the single anchoring of A.B.C.(Aerial Bundled Conductors) with insulated neutral messenger. It comprises a bracket supporting one or two anchoring clamps. | ||
Installation | Open the screw and put conductors into grooves.Tighten the shear head nut. | ||
Standard | NFC 33-042; EN 50-483 | ||
Application
Packing&Delivery
Cooperative Client
