Product Description
Material: A1-99.5%
Surface treatment: Bright
Products property: It is used to connect the aluminum conductor end
Type | Dimensions(mm) | |||
L | d | B | Φ | |
DL 16-6 | 70 | 5.8 | 16 | 6.5 |
DL 16-8 | 70 | 5.8 | 16 | 8.5 |
DL 25-8 | 75 | 7.2 | 17.5 | 8.5 |
DL 35-8 | 85 | 8.5 | 20 | 8.5 |
DL 35-10 | 85 | 8.5 | 20 | 10.5 |
DL 50-10 | 90 | 9.7 | 23 | 10.5 |
DL 70-12 | 100 | 11.5 | 26 | 12.5 |
DL 95-12 | 110 | 13.5 | 28 | 12.5 |
DL 120-14 | 120 | 15 | 31 | 14.5 |
DL 150-14 | 125 | 16.5 | 35 | 14.5 |
DL 150-16 | 125 | 16.5 | 35 | 17 |
DL 185-16 | 133 | 18.5 | 37.5 | 17 |
DL 240-16 | 140 | 21 | 40 | 17 |
DL 300-18 | 160 | 23.5 | 44.5 | 18.5 |
DL 300-20 | 160 | 23.5 | 44.5 | 21 |
